Package Intersil SSOP — 数据表
| 制造商 | Intersil |
| 系列 | SSOP |
缩小小尺寸塑料包装
参数化
| Parameters / Models | M16.209 | M20.209 | M24.209 | M28.209 |
|---|---|---|---|---|
| Family | SSOP | SSOP | SSOP | SSOP |
| Pin Count | 16 | 20 | 24 | 28 |
| Length, mm | 6.20 | 8.20 | ||
| Thickness, mm | 1.75 | 1.73 | 1.75 | 1.75 |
| Height max, mm | 1.05 | 2.00 | 2.00 | 2.00 |
| Weight, g | 0.14 | 0.151 | 0.176 | 0.22 |
| Pitch, mm | 0.65 | 0.65 | 0.65 | 0.65 |
| Peak Temperature, °C | 240 | |||
| Package Index | M16.209 | M20.209 | M24.209 | M28.209 |
