Datasheet Wago 285-604 — 数据表

2芯通过接线端子； 35毫米²;横向标记槽；仅适用于DIN 35 x 15导轨; 2.3毫米厚；铜;笼式夹

价格

Actuation type	Operating tool
Color	blue
Connectable conductor materials	Copper
Connection technology	CAGE CLAMP®
Страна происхождения	DE
Depth	115.5 mm / 4.547 inch
Design	horizontal
Fire load	1.162 MJ
Global Trade Item Number (GTIN)	4045454115357
Height from upper-edge of DIN-35 rail	52.5 mm / 2.067 inch
Insulating material	Polyamide 66 (PA 66)
Legend (ratings)	(III / 3) ≙ Overvoltage category III / Pollution degree 3
Marking level	Side marking
Number of levels	1
Rated current	125 A
Rated impulse voltage (III / 3)	8 kV
Rated voltage (III / 3)	800 V
Solid conductor	6 … 35 mm² / 8 … 2 AWG
Strip length	23 mm / 0.91 Inch
Total number of connection points	2
Total number of potentials	1
Type of mounting	DIN-35 rail
Type of wiring	Front-entry wiring
Weight	131.314 g
Width	16 mm / 0.63 inch

系列: 285 (83)

285604, 285 604
