Datasheet Wago 400-425/425-124 — 数据表
通过接线端子
价格
参数化
| Actuation type | Operating tool |
| Color | blue |
| Connectable conductor materials | Copper |
| Connection technology | Screw-clamp connection/Studs |
| Страна происхождения | FR |
| Depth | 49 mm / 1.929 inch |
| Design | horizontal |
| Global Trade Item Number (GTIN) | 4017332280303 |
| Height from upper-edge of DIN-35 rail | 46.5 mm / 1.831 inch |
| Legend (ratings) | (III / 3) ≙ Overvoltage category III / Pollution degree 3 |
| Marking level | Side marking |
| Number of levels | 1 |
| Product Group | 1 (Rail Mounted Terminal Blocks) |
| Rated current | 125 A |
| Rated impulse voltage (III / 3) | 8 kV |
| Rated voltage (III / 3) | 1000 V |
| Solid conductor | 16 … 35 mm² / 6 … 2 AWG |
| Strip length | 17 … 19 mm / 0.67 … 0.75 Inch |
| Total number of connection points | 2 |
| Total number of potentials | 1 |
| Type of mounting | DIN-35 rail |
| Type of wiring | Side-entry wiring |
| Weight | 48.8 g |
| Width | 16 mm / 0.63 inch |
