Datasheet Wago 859 — 数据表

制造商	Wago
系列	859

价格

参数化

Parameters / Models	859-110	859-402	859-402/000-005	859-402/000-006	859-402/000-029	859-403	859-403/000-005	859-403/000-006	859-403/000-029	859-404	859-404/000-005	859-404/000-006	859-404/000-029	859-405	859-405/000-005	859-405/000-006	859-405/000-029	859-406	859-406/000-005	859-406/000-006	859-406/000-029	859-407	859-407/000-005	859-407/000-006	859-407/000-029	859-408	859-408/000-005	859-408/000-006	859-408/000-029	859-409	859-409/000-005	859-409/000-006	859-409/000-029	859-410	859-410/000-005	859-410/000-006	859-410/000-029	859-500	859-501	859-525
Color	gray	light gray	red	blue	yellow	light gray	red	blue	yellow	light gray	red	blue	yellow	light gray	red	blue	yellow	light gray	red	blue	yellow	light gray	red	blue	yellow	light gray	red	blue	yellow	light gray	red	blue	yellow	light gray	red	blue	yellow		gray	gray
Connection technology	CAGE CLAMP®																																						CAGE CLAMP®
Connections (number)																																							5
Страна происхождения		DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	DE	CN
Degree of protection	IP20																																						IP20
Depth	91 mm / 3.583 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch	2.5 mm / 0.098 inch		91 mm / 3.583 inch	90.4 mm / 3.559 inch
Fine-stranded conductor	0.08 … 2.5 mm² / 28 … 14 AWG																																						0.08 … 2.5 mm² / 28 … 14 AWG
Fire load, MJ	0.313	0.01	0.008	0.008	0.008	0.016	0.013	0.013	0.013	0.021	0.016	0.017	0.017	0.026	0.02	0.021	0.021	0.032	0.023	0.023	0.023	0.037	0.027	0.027	0.027	0.043	0.031	0.031	0.031	0.048	0.036	0.036	0.036	0.053	0.039	0.043	0.043		0.308	0.142
Flammability class per UL94	V0																																						V0
Global Trade Item Number (GTIN)	4050821809654	4044918506434	4045454429805	4045454498351	4045454498283	4044918507240	4045454429812	4045454498368	4045454498290	4044918507820	4045454429829	4045454498375	4044918805810	4044918508155	4045454429836	4045454498382	4045454498306	4044918508278	4045454429843	4045454498399	4045454498313	4044918508339	4045454429850	4045454498405	4045454498320	4044918508391	4045454429867	4044918805827	4045454498337	4044918508421	4045454429874	4045454498412	4045454498344	4044918508513	4045454429881	4044918984829	4044918984843	4050821226949	4044918500494	4017332611695
Height from upper-edge of DIN-35 rail	56 mm / 2.205 inch																																						56 mm / 2.205 inch
Housing design	Terminal block																																						Terminal block
Housing material	PA 6.6																																						PA 6.6
Main product function, intermediate plate		Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Jumper	Testing accessories		End plate
Mounting position	any																																						any
Packaging type							BOX				BOX				BOX				BOX				BOX				BOX	BOX			BOX				BOX
Product Group	6 (Interface Electronics)	6 (Interface Electronics)				6 (Interface Electronics)							6 (Interface Electronics)	6 (Interface Electronics)				6 (Interface Electronics)				6 (Interface Electronics)				6 (Interface Electronics)		6 (Interface Electronics)		6 (Interface Electronics)									6 (Interface Electronics)	6 (Interface Electronics)
Rated current, A		18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18	18
Solid conductor	0.08 … 2.5 mm² / 28 … 14 AWG																																						0.08 … 2.5 mm² / 28 … 14 AWG
Strip length	5 … 6 mm / 0.2 … 0.24 Inch																																						5 … 6 mm / 0.2 … 0.24 Inch
Surrounding air (operating) temperature	-25 … 70 °C																																						-25 … 70 °C
Surrounding air (storage) temperature	-40 … 85 °C																																						-40 … 85 °C
Total number of potentials																																							5
Type of mounting	DIN-35 rail																																						DIN-35 rail
Weight, g	14.412	1.041	0.96	1.041	1.041	1.629	1.629	1.629	1.629	2.1	2.209	2.209	2.209	2.789	2.789	2.789	2.789	3.2	3.369	3.369	3.369	3.949	3.949	3.949	3.949	4.529	4.529	4.529	4.529	5.104	5.104	5.104	5.104	5.49	5.5	5.689	5.689	3.5	14.366	4.9
Width	6 mm / 0.236 inch	11 mm / 0.433 inch	11 mm / 0.433 inch	11 mm / 0.433 inch	11 mm / 0.433 inch	16 mm / 0.63 inch	16 mm / 0.63 inch	16 mm / 0.63 inch	16 mm / 0.63 inch	21 mm / 0.827 inch	21 mm / 0.827 inch	21 mm / 0.827 inch	21 mm / 0.827 inch	26 mm / 1.024 inch	26 mm / 1.024 inch	26 mm / 1.024 inch	26 mm / 1.024 inch	31 mm / 1.22 inch	31 mm / 1.22 inch	31 mm / 1.22 inch	31 mm / 1.22 inch	36 mm / 1.417 inch	36 mm / 1.417 inch	36 mm / 1.417 inch	36 mm / 1.417 inch	41 mm / 1.614 inch	41 mm / 1.614 inch	41 mm / 1.614 inch	41 mm / 1.614 inch	46 mm / 1.811 inch	46 mm / 1.811 inch	46 mm / 1.811 inch	46 mm / 1.811 inch	51 mm / 2.008 inch	51 mm / 2.008 inch	51 mm / 2.008 inch	51 mm / 2.008 inch		8 mm / 0.315 inch	1 mm / 0.039 inch
