Datasheet Wago 890-502/342-000 — 数据表

制造商Wago
系列890
零件号890-502/342-000
Datasheet Wago 890-502/342-000

应力消除外壳; 2极带锁定夹;用于1条电缆; 3.8…8.2毫米; 17.5毫米

价格

详细说明

Wago 890-502/342-000

参数化

Colorblack
Connectable sheathed cable diameter3.8 … 8.2 mm
Страна происхожденияDE
Degree of protectionIP20
Depth29.7 mm / 1.169 inch
Fire load0.064 MJ
Flammability class per UL94V0
Global Trade Item Number (GTIN)4050821765554
Height13.2 mm / 0.52 inch
Insulating materialPolyamide 66 (PA 66)
Number of Poles2
Strip length17.5 mm
Surrounding air (operating) temperature-35 … 85 °C
Weight2.111 g
Width15.6 mm / 0.614 inch

模型线

制造商分类

  • Pluggable Connection Systems

其他名称:

890502/342000, 890 502/342 000
