Manufacturer: Powerex

Description: TRANSISTOR, IGBT MODULE

Download Data Sheet

Docket:
PM20CSJ060
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
IntellimodTM Module
Three Phase IGBT Inverter Output 20 Amperes/600 Volts
A C D N Q Q Q

Specifications:

• Collector Emitter Voltage V(br)ceo: 600 V
• Collector Emitter Voltage Vces: 1.8 V
• Current Ic Continuous a Max: 20 A
• DC Collector Current: 20 A
• Module Configuration: Six
• Mounting Type: Screw
• Number of Pins: 23
• Operating Temperature Range: -20°C to +150°C
• Package / Case: Module
• Power Dissipation Max: 56 W
• Power Dissipation: 56 W
• Transistor Case Style: Module
• Transistor Polarity: N Channel
• Transistor Type:
• Voltage Vces: 600 V
