Manufacturer: Analog Devices

Description: IC, DIGITAL ISOLATOR, 50 ns, NSOIC-8

Download Data Sheet

Docket:
Dual-Channel Digital Isolator ADuM1210
FEATURES
Narrow body, RoHS-compliant, 8-lead SOIC Low power operation 5 V operation 1.1 mA per channel maximum @ 0 Mbps to 2 Mbps 3.7 mA per channel maximum @ 10 Mbps 3 V operation 0.8 mA per channel maximum @ 0 Mbps to 2 Mbps 2.2 mA per channel maximum @ 10 Mbps 3 V/5 V level translation High temperature operation: 105°C High data rate: dc to 10 Mbps (NRZ) Precise timing characteristics 3 ns maximum pulse width distortion 3 ns maximum channel-to-channel matching High common-mode transient immunity: >25 kV/s Safety and regulatory approvals UL recognition 2500 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice #5A VDE certificate of conformity DIN V VDE V 0884-10 (VDE V 0884-10): 2006-12 VIORM = 560 V peak
GENERAL DESCRIPTION
The ADuM1210 1 is a dual-channel, digital isolator based on Analog Devices, Inc.

iCoupler® technology. Combining high speed CMOS and monolithic transformer technology, this isolation component provides outstanding

Specifications:

• Number of Channels: 2
• Number of Pins: 8
• Operating Temperature Range: -40°C to +105°C
• Package / Case: SOIC
• Propagation Delay: 50 ns
• Supply Current: 4.3 mA
• Supply Voltage Range: 2.7 V to 5.5 V

RoHS: Yes
