Datasheet VS-VSKD166/16PBF - Vishay DIODE, STANDARD, 165 A, 1600 V — 数据表

详细说明

Manufacturer: Vishay

Description: DIODE, STANDARD, 165 A, 1600 V

Download Data Sheet

Specifications:

• Approval Bodies: UL
• Case Temperature Tc @ If: 100°C
• Current If @ Vf: 518 A
• Current Ifsm: 4kA
• Diode Type: Standard Recovery
• External Depth: 35 mm
• External Length / Height: 37 mm
• External Width: 94 mm
• Fixing Centres: 80 mm
• Fixing Hole Diameter: 6.5 mm
• Forward Current If Max: 165 A
• Forward Current If(AV): 165 A
• Forward Surge Current Ifsm Max: 4kA
• Forward Voltage VF Max: 1.43 V
• Forward Voltage: 880 mV
• Isolation Voltage: 3.5 kV
• Junction Temperature Tj Max: 150°C
• Junction Temperature Tj Min: -40°C
• Junction to Case Thermal Resistance A: 0.2 °C/W
• Module Configuration: Power
• Mounting Type: Screw
• Number of Phases: 1
• Number of Pins: 3
• Operating Temperature Range: -40°C to +150°C
• Package / Case: INT-A-Pak
• RMS Current If: 260 A
• Repetitive Reverse Voltage Vrrm Max: 1.6 V
• Surge Current Frequency: 50 Hz
• Termination Method: Screw Terminal
• Thread Size: M6
• Voltage Vrsm: 1.7 kV

RoHS: Yes

其他名称:

VSVSKD166/16PBF, VS VSKD166/16PBF
