Data Sheet ADL5610 Parameter Test Conditions/Comments Min Typ Max Unit
POWER INTERFACE Supply Voltage VPOS 4.75 5 5.25 V Supply Current 92 118 mA vs. Temperature −40°C ≤ TA ≤ +105°C −6/+14 mA Power Dissipation 460 mW 1 Noise figure specified includes printed circuit board (PCB) traces losses.
TYPICAL SCATTERING PARAMETERS (S-PARAMETERS)
VPOS = 5 V and TA = 25°C.
Table 2. Frequency S11 S21 S12 S22 (MHz) Magnitude (dB) Angle (°) Magnitude (dB) Angle (°) Magnitude (dB) Angle (°) Magnitude (dB) Angle (°)
30 −19.575 −21.758 18.186 +167.401 −23.536 +0.034 −12.040 −154.592 50 −13.194 +17.280 +16.748 +158.342 −24.873 −11.954 −8.336 −158.609 100 −8.023 −17.286 +13.552 +168.911 −27.865 −5.368 −5.677 −189.790 200 −10.635 −67.774 +16.801 +171.154 −24.787 −2.040 −8.176 −225.737 300 −13.978 −93.402 +17.960 +154.322 −23.679 −16.582 −10.953 −237.962 400 −16.890 −111.950 +18.355 +138.243 −23.336 −29.568 −12.818 −242.287 500 −14.057 −140.270 +18.204 −229.198 −23.467 −33.884 −10.083 +104.308 600 −15.303 −160.894 +18.339 −243.615 −23.322 −45.046 −10.629 +98.947 700 −17.025 −180.268 +18.416 −258.515 −23.214 −56.945 −11.317 +95.056 800 −18.532 −198.771 +18.434 −272.822 −23.143 −68.374 −11.700 +91.300 900 −19.926 −216.383 +18.425 −286.779 −23.102 −79.290 −11.891 +87.191 1000 −21.266 −233.373 +18.401 −300.434 −23.099 −90.132 −11.967 +82.648 1100 −22.659 −248.512 +18.366 −313.941 −23.071 −100.705 −11.951 +77.917 1200 −24.210 −262.937 +18.320 −327.244 −23.068 −111.189 −11.897 +72.400 1300 −26.057 −274.666 +18.272 −340.437 −23.063 −121.632 −11.812 +66.929 1400 −28.536 −282.527 +18.220 −353.552 −23.065 −131.946 −11.702 +61.131 1500 −31.933 −279.454 +18.166 −366.576 −23.063 −142.239 −11.599 +55.505 1600 −34.750 −255.300 +18.106 −379.548 −23.067 −152.499 −11.467 +49.533 1700 −32.172 −220.241 +18.046 −392.387 −23.070 −162.725 −11.381 +43.914 1800 −27.781 −211.620 +17.977 −405.225 −23.085 −173.046 −11.275 +38.152 1900 −24.468 −218.185 +17.916 −418.174 −23.047 −183.266 −11.132 +32.216 2000 −21.613 −222.836 +17.843 −430.638 −23.111 −193.454 −11.136 +27.227 2100 −19.342 −232.483 +17.783 −443.294 −23.127 −203.629 −11.017 +21.933 2200 −17.343 −243.288 +17.740 −455.878 −23.141 −213.605 −10.826 +16.768 2300 −15.863 −253.959 +17.682 −468.509 −23.139 −223.746 −10.670 +10.889 2400 −14.592 −264.759 +17.629 −481.088 −23.129 −233.823 −10.488 +4.907 2500 −13.521 −275.854 +17.583 −493.684 −23.123 −243.825 −10.295 −1.461 2600 −12.680 −286.432 +17.533 −506.169 −23.114 −254.026 −10.160 −8.539 2700 −11.965 −296.744 +17.494 −518.608 −23.122 −264.148 −10.022 −15.582 2800 −11.364 −307.385 +17.466 −531.068 −23.105 −274.109 −9.909 −23.543 2900 −10.983 −318.098 +17.441 −543.539 −23.013 −284.190 −9.885 −32.338 3000 −10.683 −328.063 +17.448 −555.886 −22.967 −294.664 −9.958 −41.038 3100 −10.470 −338.914 +17.468 −568.495 −22.910 −304.790 −10.016 −50.760 3200 −10.377 −349.594 +17.503 −581.114 −22.848 −315.180 −10.207 −61.042 3300 −10.454 −360.106 +17.556 −593.755 −22.757 −325.637 −10.506 −72.485 3400 −10.733 −371.185 +17.609 −606.730 −22.674 −336.157 −10.842 −85.064 3500 −11.222 −381.299 +17.683 −619.682 −22.581 −346.908 −11.291 −98.903 Rev. B | Page 5 of 16 Document Outline Features Functional Block Diagram General Description Table of Contents Revision History Specifications Typical Scattering Parameters (S-Parameters) Absolute Maximum Ratings Thermal Resistance ESD Caution Pin Configuration and Function Descriptions Typical Performance Characteristics 500 MHz to 6 GHz Frequency Band 30 MHz to 500 MHz Frequency Band General Applications Information Basic Connections Soldering Information and Recommended PCB Land Pattern W-CDMA ACPR Performance Evaluation Board Outline Dimensions Ordering Guide
