Datasheet LTC2050, LTC2050HV (Analog Devices) - 3

LTC2050/LTC2050HV
ORDER INFORMATION LEAD FREE FINISH TAPE AND REEL PART MARKING* PACKAGE DESCRIPTION SPECIFIED TEMPERATURE RANGE
LTC2050HVIS8#PBF LTC2050HVIS8#TRPBF 050HVI 8-Lead Plastic SO –40°C to 85°C LTC2050CS5 LTC2050CS5#TR LTAEG 5-Lead Plastic TSOT-23 0°C to 70°C LTC2050IS5 LTC2050IS5#TR LTAEG 5-Lead Plastic TSOT-23 –40°C to 85°C LTC2050HS5 LTC2050HS5#TR LTAEG 5-Lead Plastic TSOT-23 –40°C to 125°C LTC2050HVCS5 LTC2050HVCS5#TR LTAEH 5-Lead Plastic TSOT-23 0°C to 70°C LTC2050HVIS5 LTC2050HVIS5#TR LTAEH 5-Lead Plastic TSOT-23 –40°C to 85°C LTC2050HVHS5 LTC2050HVHS5#TR LTAEH 5-Lead Plastic TSOT-23 –40°C to 125°C LTC2050CS6 LTC2050CS6#TR LTAEJ 6-Lead Plastic TSOT-23 0°C to 70°C LTC2050IS6 LTC2050IS6#TR LTAEJ 6-Lead Plastic TSOT-23 –40°C to 85°C LTC2050HS6 LTC2050HS6#TR LTAEJ 6-Lead Plastic TSOT-23 –40°C to 125°C LTC2050HVCS6 LTC2050HVCS6#TR LTAEK 6-Lead Plastic TSOT-23 0°C to 70°C LTC2050HVIS6 LTC2050HVIS6#TR LTAEK 6-Lead Plastic TSOT-23 –40°C to 85°C LTC2050HVHS6 LTC2050HVHS6#TR LTAEK 6-Lead Plastic TSOT-23 –40°C to 125°C LTC2050CS8 LTC2050CS8#TR 2050 8-Lead Plastic SO 0°C to 70°C LTC2050IS8 LTC2050IS8#TR 2050I 8-Lead Plastic SO –40°C to 85°C LTC2050HVCS8 LTC2050HVCS8#TR 2050HV 8-Lead Plastic SO 0°C to 70°C LTC2050HVIS8 LTC2050HVIS8#TR 050HVI 8-Lead Plastic SO –40°C to 85°C Contact the factory for parts specified with wider operating temperature ranges. *The temperature grade is identified by a label on the shipping container. Tape and reel specifications. Some packages are available in 500 unit reels through designated sales channels with #TRMPBF suffix. Rev. E For more information www.analog.com 3 Document Outline Features Applications Typical Application Description Absolute Maximum Ratings Pin Configuration Order Information Electrical Characteristics Typical Performance Characteristics Test Circuits Applications Information Typical Applications Package Description Revision History Typical Application Related Parts
