ADSP-21369 GENERAL DESCRIPTION
The ADSP-21369 SHARC® processor is a member of the SIMD
Table 2. Product Features (Continued)
SHARC family of DSPs that feature Analog Devices’ Super Har- vard Architecture. These processors are source code-compatible
Feature ADSP-21369
with the ADSP-2126x and ADSP-2116x DSPs as well as with DPI Yes first generation ADSP-2106x SHARC processors in SISD (sin- gle-instruction, single-data) mode. The processors are 32- S/PDIF Transceiver 1 bit/40-bit floating-point processors optimized for high perfor- AMI Interface Bus Width 32 bits/16 bits/8 bits mance automotive audio applications with its large on-chip SRAM, mask programmable ROM, multiple internal buses to SPI 2 eliminate I/O bottlenecks, and an innovative digital applications TWI Yes interface (DAI). SRC Performance 128 dB As shown in the functional block diagram on Page 1, the processor uses two computational units to deliver a significant Shared Memory Support 256-Ball BGA only performance increase over the previous SHARC processors on a Package 256-Ball BGA, 208-Lead LQFP_EP range of DSP algorithms. Fabricated in a state-of-the-art, high speed, CMOS process, the processor achieves an instruction cycle time of up to 2.5 ns at 400 MHz. With its SIMD computa- The diagram on Page 1 shows the two clock domains. The core tional hardware, the processor can perform 2.4 GFLOPS clock domain contains the following features. running at 400 MHz. • Two processing elements (PEx, PEy), each of which com- Table 1 shows performance benchmarks for the ADSP-21369 prises an ALU, multiplier, shifter, and data register file processor. • Data address generators (DAG1, DAG2) • Program sequencer with instruction cache
Table 1. Processor Benchmarks (at 400 MHz)
• PM and DM buses capable of supporting two 64-bit data
Speed
transfers between memory and the core at every core pro-
Benchmark Algorithm (at 400 MHz)
cessor cycle 1024 Point Complex FFT (Radix 4, with Reversal) 23.2 s • One periodic interval timer with pinout FIR Filter (per Tap)1 1.25 ns • On-chip SRAM (2M bit) IIR Filter (per Biquad)1 5.0 ns • JTAG test access port for emulation and boundary scan. Matrix Multiply (Pipelined) The JTAG provides software debug through user break- [3×3] × [3×1] 11.25 ns points which allows flexible exception handling. [4×4] × [4×1] 20.0 ns The block diagram on Page 1 also shows the peripheral clock Divide (y/x) 8.75 ns domain (also known as the I/O processor) and contains the fol- Inverse Square Root 13.5 ns lowing features: 1 Assumes two files in multichannel SIMD mode. • IOD0 (periphera l DMA) and IOD1 (external port DMA) buses for 32-bit data transfers
