HMC463 v11.0617 GaAs PHEMT MMIC LOW NOISEAGC AMPLIFIER, 2 - 20 GHz 1 Typical ApplicationsFeatures The HMC463 is ideal for: Gain: 14 dB IP H • Telecom Infrastructure Noise Figure: 2.5 dB @ 10 GHz • Microwave Radio & VSAT P1dB Output Power: +19 dBm @ 10 GHz • Military & Space Supply Voltage: +5V @ 60 mA E - C • Test Instrumentation 50 Ohm Matched Input/Output IS • Fiber Optics Die Size: 3.05 x 1.29 x 0.1 mm O Functional DiagramGeneral Description W N The HMC463 is a GaAs MMIC PHEMT Low Noise O AGC Distributed Amplifier die which operates between 2 and 20 GHz. The amplifier provides 14 dB of gain, 2.5 dB noise figure and 19 dBm of output power at S - L 1 dB gain compression while requiring only 60 mA R from a +5V supply. An optional gate bias (Vgg2) is IE provided to al ow Adjustable Gain Control (AGC) of 10 dB typical. Gain flatness is excel ent at ±0.15 dB LIF from 6 - 18 GHz making the HMC463 ideal for EW, P ECM and RADAR applications. The HMC463 ampli- M Vgg2: Optional Gate Bias for AGC fier can easily be integrated into Multi-Chip-Modules A (MCMs) due to its small size. All data is with the chip in a 50 Ohm test fixture connected via 0.025mm (1 mil) diameter wire bonds of minimal length 0.31mm (12 mils). Electrical Specifications, T = +25° C, Vdd= 5V, Idd= 60 mA*A Parameter Min. Typ. Max. Min. Typ. Max. Min. Typ. Max. Units Frequency Range 2.0 - 6.0 6.0 - 18.0 18.0 - 20.0 GHz Gain 12 15 12 14 12 14 dB Gain Flatness ±1.0 ±0.15 ±0.15 dB Gain Variation Over Temperature 0.015 0.025 0.015 0.025 0.015 0.025 dB/ °C Noise Figure 3.0 4.0 2.5 3.7 3.5 4.0 dB Input Return Loss 12 15 14 dB Output Return Loss 11 12 10 dB Output Power for 1 dB Compression (P1dB) 16 19 13 16 11 14 dBm Saturated Output Power (Psat) 21 20 19 dBm Output Third Order Intercept (IP3) 31 28 26 dBm Supply Current 60 80 60 80 60 80 mA (Idd) (Vdd= 5V, Vgg1= -0.9V Typ.) * Adjust Vgg1 between -1.5 to -0.5V to achieve Idd= 60 mA typical. InF foo r r p mati r o ic n fe u , d rnis e heliv d e b r y yA, a nal n o d t g D o p evic l e a s c i e o s belird ev e e r d st: A o b n e a aclo cug D rate e a v n ic d r e el s ia , I bl n e c . H., O owevn e e T r, n e o chFn oolo r p g ri y W ce a , d y el , P ive .rO y . B , an ox 9 d t 10 o pl 6 a , N c o e or rw de o rsod : A, M nal A 0 o 2 g D 0 e 6 vi 2 c - e 9 s 10 , In6 c., responsibility is assumed by Analog Devices for its use, nor for any infringements of patents or other One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106 1 - 1 rights of third parties that may result from its use. Sp P ech ifi o c n atie o : 78 ns su 1 bj - e 3 c 2 t t 9- o c 4 ha 7 n 0 g 0 • O e withou rd t n e oti r o ce n . N li o ne at www.analog.com license is granted by implication or otherwise under any pA at p e p n li t o ca r pattio en n S t righu t p s opo f A r n t al: P o h g D o ev n ic e e : 1 s. -8P0h0 o -nAeN : 7AL 81-O3G 29--D 4700 • Order online at www.analog.com Trademarks and registered trademarks are the property of their respective owners. Application Support: Phone: 1-800-ANALOG-D
