Datasheet TMP114 (Texas Instruments) - 6

TMP114
SNIS214 – JUNE 2021
www.ti.com
Over free-air temperature range and VDD = 1.08 V to 1.98 V (unless otherwise noted); Typical specifications are at TA = 25 °C and VDD = 1.2 V (unless otherwise noted)
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
Serial bus inactive 0.16 ISD Shutdown current Shutdown mode fSCL = 400 kHz µA fSCL = 1 MHz Supply rising, Power-on VPOR Power supply thresholds 1.0 Reset V Supply failing, Brown-out VBOR Power supply thresholds 0.8 Detect Initialization time after Power-on TINIT 1 ms Reset Soft Reset or General Call TRESET Reset recovery time 1 ms Reset
AD
(1) Repeatability is the ability to reproduce a reading when the measured temperature is applied consecutively, under the same conditions. (2) One-shot mode setup, 1 sample per minute for 24 hours. (3) Long-term drift is determined using accelerated operational life testing at a junction temperature of 150°C.
